Shelly Wave Motion Z-Wave Motion Detector

The SHELLY-WAVE-PRO-DIMMER-1PM represents a sophisticated DIN rail-mounted smart dimmer solution designed for professional lighting control applications. This advanced device combines precise trailing-edge dimming capabilities with comprehensive power monitoring features, making it ideal for both residential and commercial installations where detailed energy management is required alongside lighting control.

Engineered for seamless integration into modern smart environments, the device operates on Z-Wave® wireless technology for reliable communication and supports mesh networking to extend system range. Its compact form factor and DIN rail mounting make it particularly suitable for distribution board installations where space optimisation is crucial. The unit's robust construction and comprehensive protection mechanisms ensure reliable operation across various electrical environments.

Technical Specifications

• Power Supply: 110-240 V~, 50/60 Hz
• Power Consumption: < 0.3W
• Power Measurement: Yes
• Dimming Type: Trailing edge
• Maximum Output Power: 200 W
• External Protection: 10 A, tripping characteristic B OR C, 6 KA interrupting rating, energy limiting class 3
• Wireless Protocol: Z-Wave® S800
• Frequency Band: 868.4 MHz
• Maximum RF Power: < 25 mW
• Communication Range: Up to 40 metres indoors (131 ft.), depends on local conditions
• Z-Wave® Repeater: Yes
• Dimensions: 94 × 19 × 69 mm / 3.7 × 0.75 × 2.71 in
• Weight: 75 g / 2.65 oz
• Mounting: DIN rail
• Conductor Cross Section: 0.5 to 2.5 mm² / 20 to 14 AWG (green connectors), 0.5 to 1.5 mm² / 20 to 16 AWG (white connectors)
• Ambient Temperature: -20°C to 40°C / -5°F to 105°F
• Humidity: 30% to 70% RH
• Maximum Altitude: 2000 m / 6562 ft

Key Features

• Comprehensive Protection: Integrated over-heating, over-power, and over-voltage protection systems ensure device longevity and safety
• Power Monitoring: Real-time energy consumption tracking enables detailed energy management and efficiency analysis
• Z-Wave® Mesh Networking: Functions as a repeater to strengthen network reliability and extend coverage throughout the installation
• Professional Installation: DIN rail mounting and screw terminals with specified torque settings (0.4 Nm / 3.54 lb-in) facilitate secure electrical connections
• Wide Voltage Compatibility: Supports 110-240V operation for global deployment flexibility
• Robust Construction: Lime-coloured plastic housing designed for durability in various environmental conditions

Use Cases

This dimmer is particularly suited for smart home installations requiring centralised lighting control from the consumer unit, commercial lighting systems where energy monitoring is mandated, retrofit projects in listed buildings where wireless solutions are preferred, and multi-room lighting schemes benefiting from Z-Wave® mesh networking capabilities. The combination of dimming functionality with power measurement makes it invaluable for energy auditing applications and compliance reporting.
