Shelly Pro RGBWW PM DIN-Rail Lighting Controller with Power Metering

The Shelly Pro RGBWW PM DIN-Rail Lighting Controller with Power Metering represents a sophisticated solution for modern lighting control systems. This five-channel smart lighting controller combines advanced colour management capabilities with comprehensive power monitoring functionality, making it ideal for both residential and commercial installations. Designed for DIN-rail mounting, the device seamlessly integrates into electrical distribution boards while providing professional-grade lighting control. This versatile controller supports multiple operational profiles and can be operated either as a standalone device within a local Wi-Fi network or integrated with cloud-based home automation platforms. The inclusion of real-time power metering allows users to monitor voltage, current, and power consumption directly, providing valuable insights into energy usage patterns. With its embedded web interface, users can easily configure settings, monitor performance, and control lighting parameters from any location with internet connectivity.

Technical Specifications

• Device Model: SPDC-0D5PE16EU
• Mounting Type: DIN-rail compatible
• Input Channels: 5 (supporting button, switch or analogue inputs)
• Output Channels: 5 independent channels
• Wireless Connectivity: Wi-Fi and Bluetooth with BLE Gateway functionality
• Network Features: Wi-Fi range extension capability
• Control Methods: Local network operation, cloud services, and remote access
• Supported Profiles: RGB and CCT (default), CCT x 2, RGB and lights x 2, Lights x 5

Key Features

• Multiple Profile Support: Offers four distinct operational modes including RGB and CCT combination, dual CCT channels, RGB plus dual lighting channels, and independent five-channel lighting control.
• Advanced Power Metering: Provides precise real-time monitoring of electrical parameters including voltage, current, and power consumption.
• Comprehensive Automation: Supports scripting capabilities, basic and advanced scheduling with time adjustments ranging from seconds to months, auto on/off timers, and local action scenarios.
• Enhanced Connectivity: Features both Wi-Fi and Bluetooth connectivity with BLE Gateway functionality for seamless integration with other smart devices.
• Web Interface: Includes an embedded web interface for device configuration, monitoring, and control without requiring additional software.
• Third-Party Integration: Highly compatible with major home automation systems through webhooks and standard communication protocols.

Use Cases

The Shelly Pro RGBWW PM excels in various applications including commercial lighting installations where precise colour temperature control and energy monitoring are required. It's particularly effective for LED strip lighting control in retail environments, hospitality venues, and residential settings. The five independent output channels enable control of multiple lighting zones or different colour temperatures within a single space. The power metering capability makes it suitable for energy management systems and sustainability-focused projects where monitoring consumption is crucial. The DIN-rail mounting makes it ideal for integration into existing electrical distribution systems without requiring additional enclosure space.
